1000Nm3/h-40000Nm3/h VPSA Oxygen Generator with Fully Automatic Operation and High Pressure for Industrial Use

1000Nm3/h-40000Nm3/h VPSA Oxygen Generator with Fully Automatic Operation and High Pressure for Industrial Use
1000Nm3/h-40000Nm3/h VPSA Oxygen Generator with Fully Automatic Operation and High Pressure for Industrial Use 1000Nm3/h-40000Nm3/h VPSA Oxygen Generator with Fully Automatic Operation and High Pressure for Industrial Use 1000Nm3/h-40000Nm3/h VPSA Oxygen Generator with Fully Automatic Operation and High Pressure for Industrial Use 1000Nm3/h-40000Nm3/h VPSA Oxygen Generator with Fully Automatic Operation and High Pressure for Industrial Use

Grote Afbeelding :  1000Nm3/h-40000Nm3/h VPSA Oxygen Generator with Fully Automatic Operation and High Pressure for Industrial Use

Productdetails:
Plaats van herkomst: CHINA
Merknaam: GNEE
Certificering: SGS
Betalen & Verzenden Algemene voorwaarden:
Min. bestelaantal: ≥1sets
Prijs: According to the product
Betalingscondities: MoneyGram, Western Union, T/T, D/P, D/A, L/C
Levering vermogen: 25 Elke maand
Contact

1000Nm3/h-40000Nm3/h VPSA Oxygen Generator with Fully Automatic Operation and High Pressure for Industrial Use

beschrijving
Structuur: VPSA -zuurstofgenerator Industrieel gebruik Condotie: Nieuw
Bedrijfsmodus: Continu Zuurstofzuiverheid: 93%-95%
Lege tankgewicht: 89000kgs Drukbeoordeling: Hoge druk
Operatie: Volledig automatisch Trefwoord: VPSA zuurstofcentrale
Zuiverheid: 90-95% Buitendiameter: 2000 mm
Werktemperatuur: -196 - 50 ℃ Plaatsingsmethode: Verticaal
Leven in dienst: ≥10 jaar Vermogen van de compressor: 22-110KW
Markeren:

1000Nm3/h-40000Nm3/h VPSA Oxygen Generator

,

Fully Automatic Operation VPSA Oxygen Generator

,

High Pressure VPSA Oxygen Generator

1000Nm3/h-40000Nm3/h VPSA Oxygen Plant O2 Generator
As an energy-saving oxygen production solution, the VPSA Oxygen Generator utilizes vacuum pressure swing adsorption technology with molecular sieves to adsorb nitrogen and other impurities from air at low pressure. The system regenerates adsorbents through vacuum pumps to continuously produce high-purity oxygen. Featuring automatic operation with minimal manual intervention, simple maintenance, and excellent environmental adaptability, it serves diverse applications including metallurgy, chemical processing, healthcare, and environmental protection.
Product Specifications
Gas production (Nm³/h) Air consumption (Nm³/min) Inlet diameter DN (mm) Outlet diameter DN (mm) Host dimensions L×W×H (mm)
10.2DN15DN15800×650×1720
20.4DN15DN15950×950×1500
30.6DN15DN151050×900×1865
51DN20DN151450×900×1825
102DN32DN151450×900×1825
153DN40DN251800×950×1940
204DN40DN251850×1025×2100
255DN50DN252000×1050×2210
306DN50DN252000×1050×2530
5010DN65DN252200×1250×2720
6012DN65DN402250×1300×2850
8016DN80DN402350×1550×3060
10020DN100DN402500×1600×3330
12024DN100DN402600×1700×3670
15030DN150DN404700×1500×2980
18036DN200DN404700×1600×3370
20040DN200DN405000×1600×3330
24048DN200DN505200×1700×3670
1000Nm3/h-40000Nm3/h VPSA Oxygen Generator with Fully Automatic Operation and High Pressure for Industrial Use 0 1000Nm3/h-40000Nm3/h VPSA Oxygen Generator with Fully Automatic Operation and High Pressure for Industrial Use 1 1000Nm3/h-40000Nm3/h VPSA Oxygen Generator with Fully Automatic Operation and High Pressure for Industrial Use 2
Competitive Advantages
  • Cost Efficiency: Initial investment is 60-70% lower than cryogenic plants - a 500Nm³/h system costs $200,000-$300,000 versus $400,000-$600,000 for equivalent cryogenic systems
  • Compact Footprint: Requires only 15-20m² for a 100Nm³/h system compared to 50-80m² for cryogenic alternatives
  • Energy Saving: Consumes 0.32-0.38kWh/Nm³ versus 0.6-0.8kWh/Nm³ for cryogenic distillation, saving 6,720-11,520 kWh monthly for 1000Nm³/h systems
  • Eco-Friendly: Zero chemical emissions with only harmless nitrogen byproduct
  • Durable Construction: 15-20 year lifespan for adsorption towers, 5-8 years for molecular sieves, and 8-10 years for blowers/vacuum pumps with proper maintenance
Transportation Solutions
Small-Medium Units (≤200Nm³/h)
Road transport via flatbed or enclosed trucks (5-ton capacity for 2-3 ton units). Equipment secured with steel cables and anti-slip mats. Routes planned to avoid rough terrain or weight restrictions.
Large Modular Systems (≥500Nm³/h)
Split into functional modules (adsorption tower, control system, blower, vacuum pump, pretreatment) for containerized transport. Adsorption towers (5-10 tons) require reinforced flatbed containers; control systems ship in 20-foot containers with shockproof packaging.
International Shipping
Sea freight in 20/40-foot containers with nitrogen-sealed molecular sieve modules labeled as Hazardous Goods Class 2.2. Documentation includes packing lists, commercial invoices, and certificates of origin.
We also manufacture PSA Oxygen Generators, storage tanks, and heat exchangers. For inquiries about VPSA systems or other products, contact us at info@gneeheatex.com.
