20L VPSA Oxygen Generator 1.6 MPa For Hospital Use

20L VPSA Oxygen Generator 1.6 MPa For Hospital Use
20L VPSA Oxygen Generator 1.6 MPa For Hospital Use 20L VPSA Oxygen Generator 1.6 MPa For Hospital Use 20L VPSA Oxygen Generator 1.6 MPa For Hospital Use 20L VPSA Oxygen Generator 1.6 MPa For Hospital Use

Grote Afbeelding :  20L VPSA Oxygen Generator 1.6 MPa For Hospital Use

Productdetails:
Plaats van herkomst: China
Merknaam: GNEE
Certificering: SGS
Betalen & Verzenden Algemene voorwaarden:
Min. bestelaantal: ≥1sets
Prijs: depend on product
Verpakking Details: houten doosverpakking
Betalingscondities: MoneyGram, Western Union, D/P, T/T, D/A, L/C
Contact

20L VPSA Oxygen Generator 1.6 MPa For Hospital Use

beschrijving
Drukbereik: 1.6 MPa Veiligheidsapparaat: Drukverlagend klep
Belangrijke verkooppunten: Energiebesparing Machinetestrapport: Mits
Buitenste vaartuigmateriaal: Koolstofstaal Drukbeoordeling: Hoge druk
Veiligheidsfuncties: Drukontlastkleppen, vacuümontlastkleppen, burst -schijven Plaatsingsmethode: Verticaal
Zuurstoftank: 15000 -laters vloeibare zuurstoftank Andere naam: VPSA -zuurstofapparatuur
Markeren:

20L VPSA oxygen generator

,

hospital oxygen generator 1.6 MPa

,

Hospital vpsa oxygen generator

20 Liter Medical VPSA Oxygen Generator For Hospital
Product Description
Our oxygen generator plants utilize a reliable, flexible, and trouble-free vacuum pressure swing adsorption (VPSA) process. These systems are ideal for on-stream applications requiring low-cost gaseous oxygen with purity levels of 90-95% by volume. Available in capacities ranging from 300 Nm³/h to 10,000 Nm³/h, we offer both pre-engineered, standardized containerized VPSA plants and customized solutions.
Product Parameters
Gas production (Nm³/h) Air consumption (Nm³/min) Imported nominal diameter DN (mm) Imported nominal diameter DN (mm) Air nominal diameter DN Host L*W*H (mm)
1 0.2 DN15 DN15 NT0010 800 * 650*1720
2 0.4 DN15 DN15 NT0010 950 * 950*1500
3 0.6 DN15 DN15 NT0010 1050 * 900*1865
5 1 DN20 DN15 NT0010 1450 * 900*1825
10 2 DN32 DN15 NT0020 1450 * 900*1825
15 3 DN40 DN25 NTAD-4-0 1800 * 950*1940
20 4 DN40 DN25 NTAD-6-0 1850 *1025 * 2100
25 5 DN50 DN25 NTAD-6-0 2000 *1050 * 2210
30 6 DN50 DN25 NTAD-8-0 2000 *1050 * 2530
50 10 DN65 DN25 NTAD-13-0 2200 *1250 * 2720
60 12 DN65 DN40 NTAD-15-0 2250 *1300 * 2850
80 16 DN80 DN40 NTAD-20-0 2350 *1550 * 3060
100 20 DN100 DN40 NTAD-25-0 2500 *1600 * 3330
120 24 DN100 DN40 NTAD-30-0 2600 *1700 * 3670
150 30 DN150 DN40 NTAD-40-0 4700 *1500 * 2980
180 36 DN200 DN40 NTAD-40-0 4700 *1600 * 3370
200 40 DN200 DN40 NTAD-60-0 5000 *1600 * 3330
240 48 DN200 DN50 NTAD-60-0 5200 *1700 * 3670
20L VPSA Oxygen Generator 1.6 MPa For Hospital Use 0 20L VPSA Oxygen Generator 1.6 MPa For Hospital Use 1 20L VPSA Oxygen Generator 1.6 MPa For Hospital Use 2
VPSA Oxygen Production Technology Process
  • Low-pressure raw air is transported by a blower, purified through dust removal, then enters the VPSA system's molecular sieve adsorption tower for separation
  • The adsorption tower (two-tower or three-tower system) uses specific molecular sieves to adsorb nitrogen, carbon dioxide, and water vapor while collecting oxygen in a buffer vessel
  • When adsorption reaches set control values, the adsorbent is thoroughly desorbed and regenerated through pressure reduction and vacuum pumping
  • An automatic control system (PLC or DCS) manages valve circulation to maintain continuous oxygen production
The VPSA oxygen production process offers significant advantages including low oxygen cost, minimal equipment operation cost, high automation, compact footprint, and convenient start-stop operation.
In addition to VPSA Oxygen Generators, we also produce PSA Oxygen Generators, storage tanks, heat exchangers and related products. For inquiries about VPSA Oxygen Systems or other products, please contact us at info@gneeheatex.com. We look forward to serving you.

label:

VPSA oxygen plant 300 Nm3/hr,

industrial VPSA oxygen generator,

PLC control oxygen plant
